Belzona 1131 (Bearing Metal)

Belzona 1131 (Bearing Metal) is a high-performance, two-part epoxy-based composite specifically designed for the repair and protection of worn or damaged bearing surfaces, particularly in heavy machinery and equipment. It is ideal for restoring bearings and shaft journals to their original dimensions, ensuring extended service life and reduced downtime.

Key Features

1. High Wear Resistance:
   • Excellent resistance to wear and abrasion, making it ideal for high-stress applications such as bearings and rotating equipment.
2. Good Adhesion:
   • Strong adhesion to metals, including cast iron, steel, and non-ferrous alloys, as well as other substrates.
3. Easy to Apply:
   • Simple to mix and apply, even for large and complex bearing surfaces.
4. Durability:
   • Resists corrosion, cavitation, and chemical attack, ensuring long-lasting protection.
5. Machinable:
   • Once cured, the material can be machined to the desired finish, allowing for precise dimensional restoration.
6. Temperature Resistance:
   • Can withstand operating temperatures up to 120°C (248°F), with intermittent exposure up to 150°C (302°F).

Applications

• Bearing Repairs:
  • Ideal for repairing worn or damaged bearing surfaces in motors, pumps, compressors, and other machinery.
• Shaft Journal Repairs:
  • Used for rebuilding worn shaft journals and restoring them to their original dimensions.
• Bushing and Sleeves:
  • Rebuilds and reconditions worn bushings and sleeves, restoring them to full functionality.
• Industrial Equipment:
  • Protects and restores critical equipment components exposed to heavy wear, pressure, and environmental factors.

How to Use

1. Surface Preparation:
   • Thoroughly clean and degrease the surface to remove contaminants such as oils, grease, and dirt. Abrade the surface for better bonding.
2. Mixing:
   • Mix the two components (Part A and Part B) in the specified ratio until a uniform color is achieved.
3. Application:
   • Apply the mixed compound directly to the bearing surface or shaft journal, ensuring full coverage. Smooth the material for an even finish.
4. Curing:
   • Allow the material to cure at room temperature. Full mechanical properties are typically reached within 24-48 hours.
5. Machining:
   • Once cured, the material can be machined to restore the original bearing dimensions.

Technical Specifications

• Base: Epoxy resin
• Color: Grey (when mixed)
• Compressive Strength: 80 MPa (11,600 psi)
• Adhesive Strength: 18 MPa (2,600 psi)
• Temperature Resistance:
  • Continuous: 120°C (248°F)
  • Intermittent: 150°C (302°F)
• Working Life: Approximately 1.5 to 2 hours at 20°C (68°F)

Benefits

• Restores Bearing Surfaces:
  • Effectively restores worn or damaged bearing surfaces to original dimensions, improving machinery efficiency and reliability.
• Cost-Effective:
  • Offers a cost-effective alternative to costly bearing replacements, saving time and money.
• Versatile:
  • Suitable for a wide range of applications, including machinery, industrial equipment, and automotive components.
• Non-Hazardous:
  • Safe to handle with minimal safety precautions required.

Safety Precautions

• Use personal protective equipment (PPE), including gloves and goggles, during application.
• Ensure proper ventilation during use to avoid inhalation of vapors.
• Refer to the Safety Data Sheet (SDS) for more detailed safety instructions.

Storage

• Store in a cool, dry place between 5°C and 30°C (41°F to 86°F).
• Keep the container tightly sealed when not in use to prevent contamination and prolong shelf life.

Belzona 1131 (Bearing Metal) is trusted for its ability to restore and protect critical bearing surfaces, reducing downtime and extending the lifespan of industrial equipment. Its versatility, durability, and ease of use make it an ideal choice for demanding repair applications.
